DC 4-20mA Eingang Analoger Signalisolator Konverter / Signalsplitter mit 4-20mA Ausgang

Produktbeschreibung

Other paraments can be customized,pls contact us for a customization.
Introduction
. The signal isolator provides isolated distribution power for the field transmitter, isolates the current or voltage signal by the transmitter and transmits the signal to the control room PLC DSC etc.
. Input terminal is in common use for current source,2-wires and 3-wires. The input, output and power are isolated from each other by adopting highly efficient magnetoelectric isolation technology interiorly.
. This product has 2 types,1 in/1 out,1 in/2 out,input and output signal can be customized.
. Have the advantage of high precision,high linearity and strong anti-interference.Standard 35mm DIN rail independent
Product paraments
Input signal
4~20mA, 0~20mA, 0~10mA,0~5V, 0~10V, 1~5V
(Other signals need to be customized)
Distribution voltage
24VDC
Input impedance
Current type ≤100Ω
Voltage type≥300KΩ
Output signal
Power supply
DC 18V~DC32V

Produktdetails in Bildern

Produkteigenschaften

Markenname

NONE

Batterie im Lieferumfang enthalten

no

Ursprung

CN (Herkunft)

Hochbetriebenes Chemikalienunternehmen

Acetochlor

Halbfertigprodukt

Nein

Heimwerkerbedarf

elektrisch

Anzeigetyp

Nur analog

Versorgungsspannung

DC24V

Zertifizierung

CE

Zertifizierung

FCC

Zertifizierung

RoHS-Konformität

Modellnummer

GLN

Betriebstemperatur

20~65C

Genauigkeitsklasse

0.1%fs

Product name

GLN ultra thin signal isolator

Channel

1 in 1 out/1 in 2 out

Input

4-20mA,0-20mA,0-10V,0-5V etc

Output

4-20mA,0-20mA,0-10V,0-5V etc

Power

DC24V

Choice

yes

semi_Choice

yes
