DIY LED U-HOME Mini DC Motor 5A PWM Speed Controller Schalter LED Dimmer DC3V 6V 12V 24V 35V 90W für LED Streifen LED-Panel Licht

Produktbeschreibung

ZS-X4A Mini Style DC Motor Speed Regulator controls the speed of a DC motor by adjusting Pulse-Width-Modulated (PWM). Super Mini style item with the latest low voltage technology. Adjustable speed range is 1%-100%. Incorporate a 30V 3.0A fuse, and with the protection function of reverse connect power supply. It is not only to use for dc motor controls of the speed,but also to use for adjust the LED light.ZS-X4A Mini Style DC Motor Speed Regulator controls the speed of a DC motor by adjusting Pulse-Width-Modulated (PWM). Super Mini style item with the latest low voltage technology.
Specifications
1. Operating voltage: DC3V-35V
2. Control power: Maximum 90W
3. Quiescent current: 0.01A(Standby)
4. PWM duty cycle: 1%-100%
5. PWM frequency: 10khz
6. Shell size: 30MM*24MM(Without handle) total height is 15MM
7. Incorporate one 30V 3.0A fuse, and with the protection function of reverse connect power supply.So Max rated current is 3A-3.5A, can not reach to 5A, 5A is the theoretical values of laboratory tests.
8. Material: PCB
9. Application: It is not only to use for dc motor controls of the speed,but also to use for adjust the LED light,mini fan, and Your DIY LED Panel Light
Package Including: Mini PWM DC Motor Speed Controller Led Dimmer
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

Produktdetails in Bildern

Produkteigenschaften

Markenname

DIY LED U-Home

Hochbetriebenes Chemikalienunternehmen

Keine

Ist ein intelligentes Gerät

no

Ursprung

CN (Herkunft)

Material

PCB

Artikeltyp

Dimmer

Garantie

1 Year

Modellnummer

ZS-X4A

Maximal. Ladeleistung

90W

Zertifizierung

ROHS

Zertifizierung

ce

Zertifizierung

CCC

Merkmale

Dimmer

Working Voltage

DC3V 6V 12V 24V 35V
